Dongfeng kinrun 8000L skip loader garbage truck skip loader garbage truck 0086-13635733504
Dongfeng kinrun 4x2 trash truck 8000L skip loader garbage truck
Dimensions in mm
Wheel base
5000
Overhaul length
8900
Overhaul width
2500
Overhaul height
2980
Tread
Front
1880
Rear
1800
Ground clearance
250
Cob to 2nd rear axle
3736
Cab to end of frame
5556
Frame width
860
Front overhang
1430
Rear overhang
2470
Actual weight in kg
Kerb mass
7950
Max. G.V.W
21950
Front axle payload
7500
Rear axle payload
14450
Rated payload
14000
Caluated performance
Max speed with full load and peak output of engine km/h
100km/h
Max grade ability %
30%
Min turning radius m(ft)
8
Engine
Model
Cummins Euro 3 diesel engine
Type
Turbocharging, water cooled, electronically controlled common rail injection
No.of cylinders
6 inline
Piston displacement
6700cc
Max. output
155(KW) /2500(rpm)
Max. torque
800(N.m) /1200-1700(rpm)
Alternator
28V,70A
Original kinrun chassis
Cummins engine 170-190hp
Van body made of carbon steel 4mm
