50T low bed semi trailer low bed flat trailer 0086-13635733504
Brand new 3 axles red color low bed semi trailer low bed flat trailer
1.Leg capacity 26000kg
2.Total 3 axles
3.Equip with 12 wheels
Model
9400TDP
Diemension (LxWxH)
15000×3200×2800
Payload (kg)
32000
Total weight (kg)
40000
Curb weight
8000
Material
Carbon steel Q235A
Top & Bottom
5mm thickness /
Front / Rear suspension (mm):
/1600
Front tread / Rear tread(mm):
2180/2180/2180
Wheelbase (mm):
8200+1305+1305
Spring number
10, 10, 10
Axle loading weight (kg)
24000
Approach/depature angle (°)
/18
Trailer construction
Trailer chassis
high tensile steel
Axles & suspension
3 axles, FUWA 13T with FUWA leaf spring suspension
Landing leg
FUWA at both front sides of trailer, control on the right side
Kingpin
2' JOST kingpin fixed on tensile steel plate
Braking system
Dual-ways air brake, drum brake system without ABS.
Electrical system
24V electrical system in accordance to Chinese standard(7 pins socket)
Electric wiring
Semi heat insulation cable, protected with PVC conduit
Lighting
24V electrical system in accordance to Chinese standard, tail brake, signal, reverse and fog light at rear, marker light, complete with reflective tape at rear and sides.
Rear Bumper
Steel, Manufacturer 's standard
Tyres
12+1 spare x tubeless tire 289/80-22.5
Chassis finishes
1 coat anti-rust, 1 coat base and 1 finishing coat.
